Service 2 unit G1/4 0,5-10 5µm with PC bowl, bowl guard, automatic drain and gauge G 50.10 R

Article number: 035041

Type: CL.11-10-5-B-AM-G

Series: Multi-Fix

Connection: G 1/4

Construction size: BG1

Flow: 1200 l/min

Installation position: vertical

Input pressure P1 max.: 16 bar

Medium: Compressed air, neutral gases

Control range P2 max.: 10 bar

Temperature area: -10 °C - +60 °C

Container: PC with metal protective cage

Container volume oiler: 50 cm³

Filter fineness: 5 µm

Condensate drain: Fully automatic drain

Pressure gauge: yes

Oil dosing: 1 - 2 d/min

Oil type: CL 32 according to DIN 51517 - ISO VG 32

Panel nut: no
